| Corrosion Inhibiting Compound |
Cor-Ban 22
|
Cor-Ban 22 is an aerosolized version of the Cor-Ban 27L, (BMS 3-38). This product is designed to be a long lasting, high penetration, water displacing, corrosion inhibiting compound. The finished coating is soft and self healing. |
|
|
| Static Joint, Substrates |
Cor-Ban 27L
Bulk
Cor-Ban 22
Aerosol |
Cor-Ban 27L is a non-drying CIC, effective in a wide range of temperatures. It develops a thixotropic, buff colored film that will withstand UV exposure in highly corrosive environments. It is free of chromates and other hazardous materials. Uses include floor beams, antenna, seat tracks, lavatory and the galley.
| Specs: |
QPL BMS 3-38 |
|
DPM 6210 |
|
DPM 6498 |
|
NSN |
|
6850-01-0469-7645 |
|
(quart) |
|
|
|
 |
 |
| Corrosion Inhibiting Compound |
Cor-Ban 33
Aerosol |
Cor-Ban 33 is a CIC for use when maximum penetration between surfaces is mandated. It develops a thin, self-healing film quickly and is immediately detectable. Used on cables, seat tracks, faying surfaces, galley and lavatory structures.
| Specs: |
QPL BMS 3-23 |
|
(pending) |
|
Type II, Class 1 |
|
(pending) |
|
|
|
|
|
| Aircraft Substrates |
Cor-Ban 35
Aerosol
Bulk |
Cor-Ban 35 is a long lasting, high solids and low VOC CIC with high penetration capability and water displacing properties. Aapplied in a 1.5 to 2 mil wet film thickness it dries in less than one hour to a non-tacky, salmon pink color. Cor-Ban 35 incorporates the best features of BMS 3-23 and BMS 3-29 approved products.
| Specs: |
QPL BMS 3-35 |
|
CMS 565-06 Type II |
|
NSN 6850-01-492-2932 |
|
(undyed) |
|
SIKORSKY SS 8536 |
|
Type II |
|
Gulfstream GAC115AD |
|
AIRBUS 0908-001 Type I |
|
Grade 3 |
|
0908-002 Type II Grade |
|
2 |
|
0908-003 Type III Grade |
|
2 |
|
MIL-PRF-16173 grade 4 |
|
(pending) |
|
|
|
|
|
| Small Parts |
D-5010NS
Aerosol
ZC-010
Bulk |
D-5010 NS is a powerful penetrating oil and corrosion inhibitor formulated for aircraft use. D-5010 NS dissolves rust, disperses water and leaves a thin protective film that resists corrosion, light acids and alkali solutions. D-5010 NS is widely used on small parts, in engine repair and to protect tools and equipment. It will not harm paints, plastics, rubber or plated surfaces.
| Specs: |
MIL-C-23411-Ships |
|
(superceded) |
|
|
|
|
|
| Avionics, Electronics |
D-5015NS
Aerosol
ZC-015
Bulk |
D-5015 NS is a light lubricant that forms a soft, ultra thin protective film to prevent corrosion and disperse water. It is for short-term use on critical metal surfaces in avionics, electrical and electronic components. D-5015 NS is safe for use on most paints, plastics and insulation.
| Specs: |
QPL MIL-C-81309E |
|
Type III Class 2 (aerosol) |
|
|
|
Type III Class 1 (bulk) |
|
SIKORSKY SS8536 |
|
Type I |
|
|
|
|
|
| Structural Components |
D-5023NS
Aerosol
ZC-023
Bulk |
D-5023 NS is a super penetrating, water displacing CIC. It features low film build-up, a high solids formulation and is tack free. Applications include stringers, profiles, ribs, cavities, seat rails, longerones, wide and narrow box sections, broad surface cargo holds, lav and galley sub-sections. D-5023 NS is touch dry in one hour.
| Specs: |
QPL BMS 3-23 |
|
G Type II Class 2 |
|
|
|
|
|
| Avionics, Cables |
D-5026NS
Aerosol
ZC-026
Bulk |
D-5026 NS is a concentrated version of D-5015 NS designed for medium duty use on critical metal surfaces in electronic assemblies and on electrical and mechanical cables. It is an effective corrosion inhibitor and water dispersant for larger surfaces and retains the lubricating characteristics of D-5015 NS.
| Specs: |
QPL MIL-C-81309 |
|
Type II Class 2 |
|
(aerosol) |
|
DPM-5707-1 (aerosol) |
|
Type II Class 1 (bulk) |
|
SIKORSKY SS8536 |
|
Type I |
|
|
|
|
|
| Heavy Duty, Long Term CIC |
D-5029NS
Aerosol
ZC-029
Bulk |
D-5029 NS is a one step, high penetrant CIC for long term use on all metal surfaces common in aerospace. The product is for airframe surfaces where corrosion is a high profile concern. D-5029 NS will replace many duplex systems recommended by manufacturers. It features a fast dry time, reduced VOC's, high solids, low weight and dries tack free.
| Specs: |
QPL BMS 3-29 |
|
DMS 2150A Ty1 and 2 |
|
|
|
|
|
| Long Term Storage, Self-Healing |
D-5082NS
Aerosol
ZC-082
Bulk |
D-5082 NS is a corrosion preventative for aircraft cables and out-of-service aircraft such as HMCs. It is self-healing, features a flexible petroleum base and is easily removed with common solvents. Parts coated with D-5082 NS will stand up to outdoor exposure for two years.
|
|
|
| Corrosion Inhibiting Compound |
Cor-Ban 23 |
Cor-Ban 23 is designed to be a long lasting, high penetration, water
displacing, corrosion inhibiting compound for use on high profile aircraft substrates; upper edge floor beams, wheel wells, pressure deck and center wing sections. The finished coating is non-tacky with a light reddish-pink tint. Cor-Ban 23 offers the fast dry time and thin film of BMS 3-23 and the long lasting corrosion inhibition properties of BMS 3-29. |
NA |
|
| "Fogging" Corrosion Inhibiting Compound |
Noxit 86 |
Heavy duty, water displacing, non-drying, thin film, corrosion preventive compound is specially formulated for use on highly critical metal surfaces. Noxit® 86 contains no ozone depleting chemicals. This material will be effective in contacting corrosion in all areas of the airplane and is an integral part of the corrosion control program. |
NA |
|
| Mildew Resistant Silicone Sealant |
ZC-SIL-
3000-37-1 Cartridges |
ZC-SIL-3000-37-1 is a one part silicone RTV that has been selectively pigmented to yield a versatile almond-tan color. The product will handle hot and humid environments without staining, spotting or color changes.
| Specs: |
TT-S-001543 |
|
CL A MIL-A-46106A Ty 1 |
|
|
|
NA |
|
